llvm代码混淆学习（七）

2271 字
11 分钟
llvm代码混淆学习（七）
2023-02-20
llvm代码混淆
代码混淆

写在前面

随便学学 llvm 代码混淆，顺便做个毕设，水几篇文章就当做做笔记

指令替代原理分析#

概述#

指令替代指将正常的二元运算指令（如加法、减法、异或等等），替换为等效而更复杂的指令序列，以达到混淆计算过程的目的。

例如，将 a + b 替换为 a - (-b)，将 a ^ b 替换为 (~a & b) | (a & ~b)等等。

仅支持整数运算的替换，因为替换浮点指令会造成舍入错误和误差。

混淆效果#

函数的控制流并没有发生变化，但是运算过程变得难以分辨：

image-20230222233422164
image-20230222233422164

原理#

扫描所有指令，对目标指令（加法、减法、与或非、异或）进行替换：

bool Substitution::runOnFunction(Function &F){
    for(int i = 0;i < ObfuTime;i ++){
        for(BasicBlock &BB : F){
            vector<Instruction*> origInst;
            for(Instruction &I : BB){
                origInst.push_back(&I);
            }
            for(Instruction *I : origInst){
                if(isa<BinaryOperator>(I)){
                    BinaryOperator *BI = cast<BinaryOperator>(I);
                    substitute(BI);
                }
            }
        }
    }
}

指令替代代码实现思路#

加法替换#

对于 a = b + c，实现四种替换方案：

  • addNeg：a = b - (-c)
  • addDoubleNeg：a = -(-b + (-c))
  • addRand：r = rand(); a = b + r; a = a + c; a = a - r
  • addRand2：r = rand(); a = b - r; a = a + c; a = a + r

减法替换#

对于a = b - c，实现三种替换方案：

  • subNeg：a = b + (-c)
  • subRand：r = rand(); a = b + r; a = a - c; a = a - r
  • subRand2：r = rand(); a = b - r; a = a - c; a = a + r

与替换#

对于a = b & c，实现两种替换方案：

  • andSubstitute：a = (b ^ ~c) & b
  • andSubstituteRand：r = rand(); a = ~(~b | ~c) & (r | ~r)

或替换#

对于a = b | c，实现两种替换方案：

  • orSubstitute：a = (b & c) | (b ^ c)
  • orSubstituteRand：r = rand(); a = ~(~b & ~c) & (r | ~r)

异或替换#

对于a = b ^ c，实现两种替换方案：

  • xorSubstitute：a = (~a & b) | (a & ~b)
  • xorSunstituteRand：r = rand(); a = (b ^ r) ^ (c ^ r) <=> a = (~b & r | b & ~r) ^ (~c & r | c & ~r)

指令替代代码实现#

Substitution.cpp#

replaceAllUsesWith方法：使用传入的指令替换所有用到了原指令的地方。

#include "llvm/IR/Function.h"
#include "llvm/Pass.h"
#include "llvm/Support/raw_ostream.h"
#include "llvm/IR/Instructions.h"
#include "llvm/Support/CommandLine.h"
#include "Utils.h"
#include <vector>
#include <cstdlib>
#include <ctime>
using namespace llvm;
using std::vector;


#define NUMBER_ADD_SUBST 4
#define NUMBER_SUB_SUBST 3
#define NUMBER_AND_SUBST 2
#define NUMBER_OR_SUBST 2
#define NUMBER_XOR_SUBST 2


// 混淆次数，混淆次数越多混淆结果越复杂
static cl::opt<int> ObfuTime("sub_loop", cl::init(1), cl::desc("Obfuscate a function <obfu_time> time(s)."));


namespace{
   class Substitution : public FunctionPass {
       public:
           static char ID;
           Substitution() : FunctionPass(ID) {
               srand(time(NULL));
           }


           bool runOnFunction(Function &F);


           void substitute(BinaryOperator *BI);


           // 替换 Add 指令
           void substituteAdd(BinaryOperator *BI);
           // 加法替换：a = b + c -> a = b - (-c)
           void addNeg(BinaryOperator *BI);
           // 加法替换：a = b + c -> a = -(-b + (-c))
           void addDoubleNeg(BinaryOperator *BI);
           // 加法替换：a = b + c -> r = rand (); a = b + r; a = a + c; a = a - r
           void addRand(BinaryOperator *BI);
           // 加法替换：a = b + c -> r = rand (); a = b - r; a = a + b; a = a + r
           void addRand2(BinaryOperator *BI);


           // 替换 Sub 指令
           void substituteSub(BinaryOperator *BI);
           // 减法替换：a = b - c -> a = b + (-c)
           void subNeg(BinaryOperator *BI);
           // 减法替换：a = b - c -> r = rand (); a = b + r; a = a - c; a = a - r
           void subRand(BinaryOperator *BI);
           // 减法替换：a = b - c -> a = b - r; a = a - c; a = a + r
           void subRand2(BinaryOperator *BI);


           // 替换 And 指令
           void substituteAnd(BinaryOperator *BI);
           // 与替换：a = b & c -> a = (b ^ ~c) & b
           void andSubstitute(BinaryOperator *BI);
           // 与替换：a = b & c -> a = ~(~b | ~c) & (r | ~r)
           void andSubstituteRand(BinaryOperator *BI);


           // 替换 Or 指令
           void substituteOr(BinaryOperator *BI);
           // 或替换：a = b | c -> a = (b & c) | (b ^ c)
           void orSubstitute(BinaryOperator *BI);
           // 或替换：a = b | c -> a = ~(~b & ~c) & (r | ~r)
           void orSubstituteRand(BinaryOperator *BI);


           // 替换 Xor 指令
           void substituteXor(BinaryOperator *BI);
           // 异或替换：a = b ^ c -> a = ~b & c | b & ~c
           void xorSubstitute(BinaryOperator *BI);
           // 异或替换：a = b ^ c -> (b ^ r) ^ (c ^ r) <=> (~b & r | b & ~r) ^ (~c & r | c & ~r)
           void xorSubstituteRand(BinaryOperator *BI);
   };
}


bool Substitution::runOnFunction(Function &F){
   for(int i = 0;i < ObfuTime;i ++){
       for(BasicBlock &BB : F){
           vector<Instruction*> origInst;
           for(Instruction &I : BB){
               origInst.push_back(&I);
           }
           for(Instruction *I : origInst){
               if(isa<BinaryOperator>(I)){
                   BinaryOperator *BI = cast<BinaryOperator>(I);
                   substitute(BI);
               }
           }
       }
   }
}


void Substitution::substitute(BinaryOperator *BI){
   bool flag = true;
   // getOpcode方法获取指令类型，根据 加 减 与 或 非 五种指令类型调用对应混淆算法
   switch (BI->getOpcode()) {
       case BinaryOperator::Add:
           substituteAdd(BI);
           break;
       case BinaryOperator::Sub:
           substituteSub(BI);
           break;
       case BinaryOperator::And:
           substituteAnd(BI);
           break;
       case BinaryOperator::Or:
           substituteOr(BI);
           break;
       case BinaryOperator::Xor:
           substituteXor(BI);
           break;
       default:
           flag = false;
           break;
   }
   if(flag){
       BI->eraseFromParent();
   }
}




void Substitution::substituteAdd(BinaryOperator *BI){
   int choice = rand() % NUMBER_ADD_SUBST;
   switch (choice) {
       case 0:
           addNeg(BI);
           break;
       case 1:
           addDoubleNeg(BI);
           break;
       case 2:
           addRand(BI);
           break;
       case 3:
           addRand2(BI);
           break;
       default:
           break;
   }
}


void Substitution::addNeg(BinaryOperator *BI){
   // a = b + c -> a = b - (-c)
   BinaryOperator *op;
   // Neg 取负数，取第二个操作数
   op = BinaryOperator::CreateNeg(BI->getOperand(1), "", BI);
   // 创建 b - (-c)
   op = BinaryOperator::CreateSub(BI->getOperand(0), op, "", BI);
   BI->replaceAllUsesWith(op);
}


void Substitution::addDoubleNeg(BinaryOperator *BI){
   // a = b + c -> a = -(-b + (-c))
   BinaryOperator *op, *op1, *op2;
   // b 取负
   op1 = BinaryOperator::CreateNeg(BI->getOperand(0), "", BI);
   // c 取负
   op2 = BinaryOperator::CreateNeg(BI->getOperand(1), "", BI);
   // 创建 -b + (-c)
   op = BinaryOperator::CreateAdd(op1, op2, "", BI);
   // -b + (-c) 取负
   op = BinaryOperator::CreateNeg(op, "", BI);
   BI->replaceAllUsesWith(op);
}


void Substitution::addRand(BinaryOperator *BI){
   // a = b + c -> r = rand (); a = b + r; a = a + c; a = a - r
   // llvm::Value有一个llvm::Type*,getType方法可以获取其类型
   // (ConstantInt*)是强制类型转换
   ConstantInt *r = (ConstantInt*)CONST(BI->getType(), rand());
   BinaryOperator *op, *op1, *op2;
   // b + r
   op = BinaryOperator::CreateAdd(BI->getOperand(0), r, "", BI);
   // b + r + c
   op = BinaryOperator::CreateAdd(op, BI->getOperand(1), "", BI);
   // b + r + c - r = b + c
   op = BinaryOperator::CreateSub(op, r, "", BI);
   BI->replaceAllUsesWith(op);
}


void Substitution::addRand2(BinaryOperator *BI){
   // a = b + c -> r = rand (); a = b - r; a = a + c; a = a + r
   ConstantInt *r = (ConstantInt*)CONST(BI->getType(), rand());
   BinaryOperator *op, *op1, *op2;
   // b - r
   op = BinaryOperator::CreateSub(BI->getOperand(0), r, "", BI);
   // b - r + c
   op = BinaryOperator::CreateAdd(op, BI->getOperand(1), "", BI);
   // b - r + c + r
   op = BinaryOperator::CreateAdd(op, r, "", BI);
   BI->replaceAllUsesWith(op);
}


void Substitution::substituteSub(BinaryOperator *BI){
   int choice = rand() % NUMBER_SUB_SUBST;
   switch (choice) {
       case 0:
           subNeg(BI);
           break;
       case 1:
           subRand(BI);
           break;
       case 2:
           subRand2(BI);
           break;
       default:
           break;
   }
}


void Substitution::subNeg(BinaryOperator *BI){
   // a = b - c -> a = b + (-c)
   BinaryOperator *op;
   // -c
   op = BinaryOperator::CreateNeg(BI->getOperand(1), "", BI);
   // b + (-c)
   op = BinaryOperator::CreateAdd(BI->getOperand(0), op, "", BI);
   BI->replaceAllUsesWith(op);
}


void Substitution::subRand(BinaryOperator *BI){
   // a = b - c -> r = rand (); a = b + r; a = a - c; a = a - r
   ConstantInt *r = (ConstantInt*)CONST(BI->getType(), rand());
   BinaryOperator *op, *op1, *op2;
   // b + r
   op = BinaryOperator::CreateAdd(BI->getOperand(0), r, "", BI);
   // b + r - c
   op = BinaryOperator::CreateSub(op, BI->getOperand(1), "", BI);
   // b + r - c - r
   op = BinaryOperator::CreateSub(op, r, "", BI);
   BI->replaceAllUsesWith(op);
}


void Substitution::subRand2(BinaryOperator *BI){
   // a = b - c -> r = rand (); a = b - r; a = a - c; a = a + r
   ConstantInt *r = (ConstantInt*)CONST(BI->getType(), rand());
   BinaryOperator *op, *op1, *op2;
   // b - r
   op = BinaryOperator::CreateSub(BI->getOperand(0), r, "", BI);
   // b - r - c
   op = BinaryOperator::CreateSub(op, BI->getOperand(1), "", BI);
   // b - r - c + r
   op = BinaryOperator::CreateAdd(op, r, "", BI);
   BI->replaceAllUsesWith(op);
}


void Substitution::substituteXor(BinaryOperator *BI){
   int choice = rand() % NUMBER_XOR_SUBST;
   switch (choice) {
       case 0:
           xorSubstitute(BI);
           break;
       case 1:
           xorSubstituteRand(BI);
           break;
       default:
           break;
   }
}


void Substitution::xorSubstitute(BinaryOperator *BI){
   // a = b ^ c -> a = ~b & c | b & ~c
   BinaryOperator *op, *op1, *op2, *op3;
   // ~b
   op1 = BinaryOperator::CreateNot(BI->getOperand(0), "", BI);
   // ~b & c
   op1 = BinaryOperator::CreateAnd(op1, BI->getOperand(1), "", BI);
   // -c
   op2 = BinaryOperator::CreateNot(BI->getOperand(1), "", BI);
   // b & ~c
   op2 = BinaryOperator::CreateAnd(BI->getOperand(0), op2, "", BI);
   // ~b & c | b & ~c
   op = BinaryOperator::CreateOr(op1, op2, "", BI);
   BI->replaceAllUsesWith(op);
}


void Substitution::xorSubstituteRand(BinaryOperator *BI){
   // a = b ^ c -> r = rand (); (b ^ r) ^ (c ^ r) <=> (~b & r | b & ~r) ^ (~c & r | c & ~r)
   ConstantInt *r = (ConstantInt*)CONST(BI->getType(), rand());
   BinaryOperator *op, *op1, *op2, *op3;
   // ~b
   op1 = BinaryOperator::CreateNot(BI->getOperand(0), "", BI);
   // ~b & r
   op1 = BinaryOperator::CreateAnd(op1, r, "", BI);
   // ~r
   op2 = BinaryOperator::CreateNot(r, "", BI);
   // b & ~r
   op2 = BinaryOperator::CreateAnd(BI->getOperand(0), op2, "", BI);
   // ~b & r | b & ~r
   op = BinaryOperator::CreateOr(op1, op2, "", BI);
   // ~c
   op1 = BinaryOperator::CreateNot(BI->getOperand(1), "", BI);
   // ~c & r
   op1 = BinaryOperator::CreateAnd(op1, r, "", BI);
   // ~r
   op2 = BinaryOperator::CreateNot(r, "", BI);
   // c & ~r
   op2 = BinaryOperator::CreateAnd(BI->getOperand(1), op2, "", BI);
   // ~c & r | c & ~r
   op3 = BinaryOperator::CreateOr(op1, op2, "", BI);
   // (~b & r | b & ~r) ^ (~c & r | c & ~r)
   op = BinaryOperator::CreateXor(op, op3, "", BI);
   BI->replaceAllUsesWith(op);
}


void Substitution::substituteAnd(BinaryOperator *BI){
   int choice = rand() % NUMBER_AND_SUBST;
   switch (choice) {
       case 0:
           andSubstitute(BI);
           break;
       case 1:
           andSubstituteRand(BI);
           break;
       default:
           break;
   }
}


void Substitution::andSubstitute(BinaryOperator *BI){
   // a = b & c -> a = (b ^ ~c) & b
   BinaryOperator *op;
   // ~c
   op = BinaryOperator::CreateNot(BI->getOperand(1), "", BI);
   // b ^ ~c
   op = BinaryOperator::CreateXor(BI->getOperand(0), op, "", BI);
   // (b ^ ~c) & b
   op = BinaryOperator::CreateAnd(op, BI->getOperand(0), "", BI);
   BI->replaceAllUsesWith(op);
}


void Substitution::andSubstituteRand(BinaryOperator *BI){
   // a = b & c -> r = rand (); a = ~(~b | ~c) & (r | ~r)
   ConstantInt *r = (ConstantInt*)CONST(BI->getType(), rand());
   BinaryOperator *op, *op1;
   // ~b
   op = BinaryOperator::CreateNot(BI->getOperand(0), "", BI);
   // ~c
   op1 = BinaryOperator::CreateNot(BI->getOperand(1), "", BI);
   // ~b | ~c
   op = BinaryOperator::CreateOr(op, op1, "", BI);
   // ~(~b | ~c)
   op = BinaryOperator::CreateNot(op, "", BI);
   // ~r
   op1 = BinaryOperator::CreateNot(r, "", BI);
   // r | ~r
   op1 = BinaryOperator::CreateOr(r, op1, "", BI);
   // ~(~b | ~c) & (r | ~r)
   op = BinaryOperator::CreateAnd(op, op1, "", BI);
   BI->replaceAllUsesWith(op);
}


void Substitution::substituteOr(BinaryOperator *BI){
   int choice = rand() % NUMBER_OR_SUBST;
   switch (choice) {
       case 0:
           orSubstitute(BI);
           break;
       case 1:
           orSubstituteRand(BI);
           break;
       default:
           break;
   }
}


void Substitution::orSubstitute(BinaryOperator *BI){
   // a = b | c -> a = (b & c) | (b ^ c)
   BinaryOperator *op, *op1;
   // b & c
   op = BinaryOperator::CreateAnd(BI->getOperand(0), BI->getOperand(1), "", BI);
   // b ^ c
   op1 = BinaryOperator::CreateXor(BI->getOperand(0), BI->getOperand(1), "", BI);
   // (b & c) | (b ^ c)
   op = BinaryOperator::CreateOr(op, op1, "", BI);
   BI->replaceAllUsesWith(op);
}


void Substitution::orSubstituteRand(BinaryOperator *BI){
   // a = b | c -> r = rand (); a = ~(~b & ~c) & (r | ~r)
   ConstantInt *r = (ConstantInt*)CONST(BI->getType(), rand());
   BinaryOperator *op, *op1;
   // ~b
   op = BinaryOperator::CreateNot(BI->getOperand(0), "", BI);
   // ~c
   op1 = BinaryOperator::CreateNot(BI->getOperand(1), "", BI);
   // ~b & ~c
   op = BinaryOperator::CreateAnd(op, op1, "", BI);
   // ~(~b & ~c)
   op = BinaryOperator::CreateNot(op, "", BI);
   // ~r
   op1 = BinaryOperator::CreateNot(r, "", BI);
   // r | ~r
   op1 = BinaryOperator::CreateOr(r, op1, "", BI);
   // ~(~b & ~c) & (r | ~r)
   op = BinaryOperator::CreateAnd(op, op1, "", BI);
   BI->replaceAllUsesWith(op);
}


char Substitution::ID = 0;
static RegisterPass<Substitution> X("sub", "Replace a binary instruction with equivalent instructions.");

文章分享

如果这篇文章对你有帮助，欢迎分享给更多人！

llvm代码混淆学习（七）
https://c1everf0x.cn/posts/llvm-obfuscation-7/
作者
C1everF0x
发布于
2023-02-20
许可协议
CC BY-NC-SA 4.0
llvm代码混淆学习（六）
llvm代码混淆学习（五）
相关文章智能推荐
1
llvm代码混淆学习（九）
llvm代码混淆随便学学，顺便做个毕设
2
llvm代码混淆学习（八）
llvm代码混淆随便学学，顺便做个毕设
3
llvm代码混淆学习（六）
llvm代码混淆随便学学，顺便做个毕设
4
llvm代码混淆学习（五）
llvm代码混淆随便学学，顺便做个毕设
5
llvm代码混淆学习（四）
llvm代码混淆随便学学，顺便做个毕设
随机文章随机推荐
Profile Image of the Author
C1everF0x
压力面前保持优雅
animals
Astro TailwindCSS EdgeOne Vercel Copyright
桂ICP备2026018046号-1 ⌛小破站正在加载...
© 2026C1everF0x. All Rights Reserved.RSSSitemap
Powered byAstroFirefly
